General Information
Manufacturer
Velleman
Part Number
VM140
Product Type
DIY Electronic Project
Miscellaneous
Features
8 analogue 10 bit resolution inputs: 0…5 or 10VDC / 20k ohms
8 analogue 8 bit resolution outputs: 0…5V or 10VDC / 47 ohms
8 digital inputs: open collector compatible (connection to GND=0) with on-board LED indication
8 digital open collector outputs (max. 50V/100mA) with on-board LED indication
One 10 bit PWM output: 0 to 100% open collector output (max 100mA / 40V) with on-board LED indication
USB port: USB 1.1 & 2.0 compatible
8 analogue 8 bit resolution outputs: 0…5V or 10VDC / 47 ohms
8 digital inputs: open collector compatible (connection to GND=0) with on-board LED indication
8 digital open collector outputs (max. 50V/100mA) with on-board LED indication
One 10 bit PWM output: 0 to 100% open collector output (max 100mA / 40V) with on-board LED indication
USB port: USB 1.1 & 2.0 compatible
Specifications
Power consumption through USB port: approx. 60mA
Up to 8 cards can be connected to PC
Power supply through adapter: 12VDC / 300mA (PS1205)
PWM frequency: 15.6kHz
Command execution time: between 21 and 48ms
PCB dimensions: 7.68 x 5.59 x 0.79"
Minimum system requirements:
Pentium class CPU or higher with free USB port (1.1 or higher)
Microsoft Windows 2000 or Windows XP
CD-ROM player and mouse
Up to 8 cards can be connected to PC
Power supply through adapter: 12VDC / 300mA (PS1205)
PWM frequency: 15.6kHz
Command execution time: between 21 and 48ms
PCB dimensions: 7.68 x 5.59 x 0.79"
Minimum system requirements:
Pentium class CPU or higher with free USB port (1.1 or higher)
Microsoft Windows 2000 or Windows XP
CD-ROM player and mouse
Item Weight
5 ounces
