General Information
Manufacturer
Velleman
Part Number
K8600
Product Type
DIY Kit - 3D Printer
Miscellaneous
Skill Level
Master
Features
QUALITY & SIZE
At under 10 inches tall and under 6 inches wide, print with the same, high-quality as the K8400 at a fraction of the size. Use 1.75 mm PLA or ABS filament to create professional quality 3D prints right from your desk.
MAGNETIC REMOVEABLE BED PLATE
The metal Nano bed plate magnetically attaches to the bed holder. After a print is completed, detach the bed plate for easy print removal.
BED LEVELING MEMORY
Manually set your bed leveling settings and save them to the K8600's memory.
ISOLATOR UPGRADE
Hotend isolator guides have upgraded from the K8400's plastic model to a new metal version. A fan is also attached to the hotend isolator to assist in temperature control.
PEACE AND QUIET PRINTING
Print your prototypes and projects in near silence with a low operating noise level of 45 dBA.
At under 10 inches tall and under 6 inches wide, print with the same, high-quality as the K8400 at a fraction of the size. Use 1.75 mm PLA or ABS filament to create professional quality 3D prints right from your desk.
MAGNETIC REMOVEABLE BED PLATE
The metal Nano bed plate magnetically attaches to the bed holder. After a print is completed, detach the bed plate for easy print removal.
BED LEVELING MEMORY
Manually set your bed leveling settings and save them to the K8600's memory.
ISOLATOR UPGRADE
Hotend isolator guides have upgraded from the K8400's plastic model to a new metal version. A fan is also attached to the hotend isolator to assist in temperature control.
PEACE AND QUIET PRINTING
Print your prototypes and projects in near silence with a low operating noise level of 45 dBA.
Specifications
Printing:
Print technology: Fused Filament Fabrication (FFF)
layer resolution: standard: 0.1 mm (maximum: 0.2 mm - minimum: 0.05 mm)
Build Plate: 80 x 80 mm / 3.15" x 3.15"
Build Volume: 80 x 80 x 75 mm / 3.15" x 3.15" x 2.95"
Build Plate Surface: Metal plate with BuildTak™ (consumable; also sold separately)
Print Speed: 40mm/s
Travel Speed: 70mm/s
Filament Diameter: 1.75 mm
Prints: PLA, ABS (testing with other materials in progress)
Maximum Nozzle Operating Temperature: 245 °C
Software:
Firmware: Modified Open Source Marlin 3D Printer. Firmware - user upgradable
Software: Repetier - CuraEngine - Slic3r (RepRap compatible)
Hardware:
Dimensions: 230 x 150 x 160 mm / 9" x 5.9" x 6.3"
Frame: sturdy, metal frame
Average noise level during operation: 45dB(A)
Ambient operation temperature: max 25 °C
Storage temperature: - 10 °C to + 40 °C
Electrical:
Communication: an SD card for direct printing and a USB connection for updates
Controller board: AVR ATmega2560 based
Display: 4 x 20 char. blue LCD with white backlight
AC input: 100-240 V~, 50/60Hz
LED illuminated logo
Print technology: Fused Filament Fabrication (FFF)
layer resolution: standard: 0.1 mm (maximum: 0.2 mm - minimum: 0.05 mm)
Build Plate: 80 x 80 mm / 3.15" x 3.15"
Build Volume: 80 x 80 x 75 mm / 3.15" x 3.15" x 2.95"
Build Plate Surface: Metal plate with BuildTak™ (consumable; also sold separately)
Print Speed: 40mm/s
Travel Speed: 70mm/s
Filament Diameter: 1.75 mm
Prints: PLA, ABS (testing with other materials in progress)
Maximum Nozzle Operating Temperature: 245 °C
Software:
Firmware: Modified Open Source Marlin 3D Printer. Firmware - user upgradable
Software: Repetier - CuraEngine - Slic3r (RepRap compatible)
Hardware:
Dimensions: 230 x 150 x 160 mm / 9" x 5.9" x 6.3"
Frame: sturdy, metal frame
Average noise level during operation: 45dB(A)
Ambient operation temperature: max 25 °C
Storage temperature: - 10 °C to + 40 °C
Electrical:
Communication: an SD card for direct printing and a USB connection for updates
Controller board: AVR ATmega2560 based
Display: 4 x 20 char. blue LCD with white backlight
AC input: 100-240 V~, 50/60Hz
LED illuminated logo
Item Weight
6 lbs
