General Information
Manufacturer
Bytecc
Part Number
DA100
Product Type
Adapter
Technical Information
Adapter Type
VGA/YPbPr to HDMI Converter
Connector on First End
VGA
Connector on Second End
HDMI
Color
Black
Features
Converts component video (YPbPr)+Audio or VGA+Audio to HDMI* singal. It can be used for PS2/STB/DVD/DVB/HDTV/PC/Laptop/WII/Xbox 360 /projector
1 channel YpbPr input, 1 channel left and right sound input, 1 channel HDMI* output. Transform HD, YpbPr and left, right track signal into HDMI* signal
1 channel VGA input, 1 channel AUDIO input, 1 channel HDMI* output
Transform the VGA signal of PC and AUDIO signal into HDMI* signal output
HDCP compliant
Easy to Use: Install in seconds, no need for setting
Achieves long-distance transmission of HDMI* signal of more than 15 meters
Support VGA resolution: 640*480@60Hz/75Hz/85Hz; 800*600@60Hz/75Hz/85Hz; 1024*768@60Hz/75Hz/85Hz; 1280*960@60Hz/75Hz/85Hz
Support YPbPr resolution: 480i/480p@60Hz; 576i/576p@50Hz; 720i/720p@60Hz; 1080i/1080p@50Hz/60Hz
1 channel YpbPr input, 1 channel left and right sound input, 1 channel HDMI* output. Transform HD, YpbPr and left, right track signal into HDMI* signal
1 channel VGA input, 1 channel AUDIO input, 1 channel HDMI* output
Transform the VGA signal of PC and AUDIO signal into HDMI* signal output
HDCP compliant
Easy to Use: Install in seconds, no need for setting
Achieves long-distance transmission of HDMI* signal of more than 15 meters
Support VGA resolution: 640*480@60Hz/75Hz/85Hz; 800*600@60Hz/75Hz/85Hz; 1024*768@60Hz/75Hz/85Hz; 1280*960@60Hz/75Hz/85Hz
Support YPbPr resolution: 480i/480p@60Hz; 576i/576p@50Hz; 720i/720p@60Hz; 1080i/1080p@50Hz/60Hz
