General Information
Manufacturer
Bytecc
Part Number
BT-555
Product Type
Switch
Specifications
Color
Black
Miscellaneous
Features
Standards
IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3az
Port
5 10/100M Auto-Negotiation RJ45 port（Auto MDI/MDIX）
1 uplink port
Network Media (Cable)
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
MAC address table
2k
Transfer Method
Store-and-Forward
Switching Capacity
1Gbps
Frame Filtering and Forward Rate
10Mbps: 14880pps
100Mbps: 148800pps
Power Supply/Consume
Input: DC5V/500mA
Consume: 0.9W
Environment
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~90% non-condensing
