General Information
Manufacturer
SilverStone Technology
Part Number
GM400-S
Product Type
Power Supply
Power Description
Input Voltage Type
AC
Input Voltage
110 VAC
Number of +12V Rails
Single
Output Voltage
+3.3V@24A
+5V@24A
+12V1@32A
+5VSB@3.5A
-12V@0.8A
+5V@24A
+12V1@32A
+5VSB@3.5A
-12V@0.8A
Physical Characteristics
Weight (Approximate)
7.05 lbs
Technical Information
Efficiency
85%~89% at 20%~100% loading with single modular
Number of Fans
2x dual 40 mm DC fans
Protection Type
Over Current Protection
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Interfaces Ports
Connectors
1 x 24 / 20-Pin Motherboard connector（500mm）
1 x 8-Pin EPS connector（500mm）
1 x 4-Pin ATX 12V connector（500mm）
2 x 6-Pin PCIE connector（500mm）
4 x SATA connector（"500mm / 150mm" x 2）
8 x 4-Pin Peripheral connector（"500mm / 150mm"x4）
2 x 4-Pin Floppy connector（"500mm / 150mm / 150mm"x2 ）
1 x 8-Pin EPS connector（500mm）
1 x 4-Pin ATX 12V connector（500mm）
2 x 6-Pin PCIE connector（500mm）
4 x SATA connector（"500mm / 150mm" x 2）
8 x 4-Pin Peripheral connector（"500mm / 150mm"x4）
2 x 4-Pin Floppy connector（"500mm / 150mm / 150mm"x2 ）
